Description
Product Paramters:
Specification:
|
Model |
MW-C50 |
MW-C70 |
MW-C100 |
MW-C200 |
MW-C500 |
|
Laser power |
50W |
70W |
100W |
200W |
350W |
|
Laser wavelength |
1064nm |
||||
|
Pulse frequency |
20-100KHz |
20-100KHz |
20-200KHz |
20-50KHz |
20-50KHZ |
|
Type of cooling |
Air-Cooled |
Air-Cooled |
Air-Cooled |
Water-Cooled |
Water-Cooled |
|
Dimensions |
760mmX780X790mm |
1100x950x700mm |
|||
|
Total weight |
56kg |
60kg |
65kg |
130kg (include water tank) |
280kg (include water tank) |
|
Total power |
350W |
500W |
600W |
1000W |
3500W |
|
Scan width |
10-80mm |
||||
|
Choices |
Handheld/Automatic |
||||
|
Working temperature |
5-40℃ |
||||
Advantages:
1. Tolerance can be up to 20mm;
2. Non contact, step coverage;
3. Can be hand-held, easy operation
4. Precise size cleaning;
5.Low base metal damage;
6. Zero consumables, low input, no chemical residue pollution.
7.100,000 hours life span.
Feature:
1. The beam emitted by the laser is absorbed by the contaminated layer on the surface to be treated.
2.Absorption of large energy forms a rapidly expanding plasma (a highly ionized unstable gas) that produces a shock wave.
3. Shock waves cause the contaminants to become fragments and are rejected.
4. The light pulse width must be short enough to avoid heat build-up that would damage the surface being treated.
5.Experiments have shown that when there is an oxide on the surface of the metal, the plasma is generated on the metal surface.
Sample:
Our service:
1. Core technology. When we were a small factory, we have focused on the development of core components such as laser power supplies and optical path. Unlike other suppliers, they only sell through assembly equipment.
2. Independent research and development department.This means we can offer our customers customized machines and improve the equipment according to market changes
3. Dealer support plan. In the early stage of customers' market development, we provide technical parameters for the installation and use of equipment free of charge, share good marketing methods, help customers win the market and achieve success.
4. Strict testing. All of the suppliers we work with come from world-class manufacturers. Before the delivery, each machine needs to be tested and inspected for 48 hours (marking machine, welding machine) and 4-7 days (cutting machine) to ensure quality and safety.
5. Timely delivery. Each machine has an accurate assembly process and strict time control to ensure that customers receive goods in a timely manner.
6. After-sales service and guarantee. We offer a 2-year warranty and any problems occur during the period and we have a responsibility to resolve them. If any part of the machine is broken, we will repair it for free and send free accessories.
