Description
Specifications:
Laser medium
Nd3+:YAG
Laser Wavelength
1.064mm
Output power
200W
Pulse width
0.2~15ms adjustable
Pulse Repeated Frequency
1~20Hz adjustable
Maximum single pulse power
≥100J
Maximum input power
7KW
Main parts
Brief describing
Laser
Φ7 superior YAG crystal， ceramic focus cavity
Laser power supply
LS-W200 pulse power supply
Special Cooling System
Unitization special chiller，over temperature alarming，flow protecting。
Control System
Singalchip(pic)
Viewing System
10X microscope viewing system
Laser medium: Nd3+:YAG Wavelength: 1.06mm Pump lamp: pulsed Xenon lamp
Pulse frequency: 0~15Hz adjustable Pulse width: 0.2~15ms adjustable
Energy of the single pulse: 0~100 J Laser power: 200W.
Advantages:
1.Mini size: the laser welding machine is 85*50*36cm
2.Wide range of application: all kinds of metal like gold,sillver,bronze,aluminum.steel and titanium
3.High power with high speed, the energy power of laser can reach 100J,and freqency of laser can be increased.
4.Easy operation,the laser control system is very simple,user can learn it after only 20 minutes training.
Features:
1. Laser is high precision (0.1-2mm spot size)welding methold and laser beam is very thin.
2.Laser is quick, Frequency can reach 20HZ.
3. Jewelry,glasses frame,mould,dental teeth need laser welding way which have beautiful welding joints .
4.Jewelry Laser welding machine is widely used in all kinds of metal like gold,sillver,bronze,aluminum.steel and titanium!
5.Laser welding is new product, Buying this product can help you win advanced cleaning market!
6.We manufacture power supply which have big advantage in prices and after sale service.
7.Engineer door to door service.
Sample:
Services:
1. Core technology. When we were a small factory, we have focused on the development of core components such as laser power supplies and optical path. Unlike other suppliers, they only sell through assembly equipment.
2. Independent research and development department. This means we can offer our customers customized machines and improve the equipment according to market changes
3. Dealer support plan. In the early stage of customers' market development, we provide technical parameters for the installation and use of equipment free of charge, share good marketing methods, help customers win the market and achieve success.
4. Strict testing. All of the suppliers we work with come from world-class manufacturers. Before the delivery, each machine needs to be tested and inspected for 48 hours (marking machine, welding machine) and 4-7 days (cutting machine) to ensure quality and safety.
5. Timely delivery. Each machine has an accurate assembly process and strict time control to ensure that customers receive goods in a timely manner.
6. After-sales service and guarantee. We offer a 2-year warranty and any problems occur during the period and we have a responsibility to resolve them. If any part of the machine is broken, we will repair it for free and send free accessories.
